Volume 2-0316

March 2016
order form
The Advanced Packaging Update (2-0316) describes the latest trends in laminate substrates for flip chip BGAs and CSPs. An update on silicon interposers and alternatives, including organic interposers, is also provided. TechSearch International’s annual survey on substrate design rules includes substrate design rules from suppliers of organic flip chip BGA and CSP substrates, PBGAs, and laminate CSPs (FBGAs) worldwide. The design rules include body size, core thickness, via and pad diameter, minimum bump pitch supported, and substrate finish. A special feature section examines the growing market for fingerprint sensors with detailed examples.
  • Contents…
    • 1 Industry and Economic Trends
      • ​1.1 Economic Trends
        • Macroeconomic Trends
    • ​2 Fingerprint Sensors
      • 2.1 Apple
      • 2.2 Fingerprint Cards
        • 2.2.1 CrucialTec and FPC in Sony Xperia Z5
      • 2.3 Synaptics
      • 2.4 Goodix Invisible Fingerprint Sensor
      • 2.5 IDEX Off-Chip Touch Sensor
      • 2.6 Ultrasonic Wave Sensors
        • Qualcomm, Sonavation, InvenSense
      • 2.7 NEXT Biometrics Active Thermal Sensing
      • 2.8 Vkansee Optical Fingerprint Sensor
      • 2.9 OSAT Developments
    • 3 Laminate Substrate Trends
      • 3.1 Flip Chip PBGA
        • 3.1.1 Bump Pitch
        • 3.1.2 Package Sizes
        • 3.1.3 Substrate Trends
        • 3.1.4 Thermal Challenges
        • 3.1.5 Substrate Warpage
      • 3.2 Flip Chip CSP
        • 3.2.1 Package Trends
      • 3.3 Coreless Substrates
      • 3.4 Interposers for High-Performance Packaging
      • 3.5 Alternatives to Silicon Interposers
        • 3.5.1 Intel's EMIB
        • 3.5.2 Organic Interposers
    • 4 Substrate Design Rules
      • 4.1 Today's Laminate Feature Size
      • 4.2 Company Design Rules
        • Access, ASE Materials, AT&S, Daeduck, Daisho Denshi, Eastern, Fujitsu, Ibiden, i3 Electronics, Kinsus, Kyocera, LG Innotek, Nan Ya PCB, SEMCO, Samsung Techwin, Shennan Circuits, Simmtech, Toppan Printing, Tripod, Unimicron
    • References
  • Figures…
    • 1.1 Monthly U.S. housing starts
    • 2.1 Fingerprint sensor market for mobile devices
    • 2.2 Touch ID 2 is two-die stack with 29 TSVs
    • 2.3 CrucialTec's Biometric TrackPad
    • 2.4 Synaptics Natural IDTM fingerprint sensor
    • 2.5 Synaptics FS4304 fingerprint sensor
    • 2.6 IDEX fingerprint sensor cost comparison
    • 2.7 Sonavation ultrasonic fingerprint sensors
    • 2.8 CMOS-MEMS ultrasonic sensor
    • 2.9 NEXT's bezel-less sensor for smartphones
    • 2.10 Vkansee optical sensor
    • 2.11 TSV versus trench/RDL for fingerprint sensor
    • 3.1 Organic interposer test vehicle for HBM
  • Tables…
    • 2.1 Biometric ID Technology Characteristics
    • 2.2 Touch Fingerprint Sensor Suppliers
    • 2.3 Fingerprint Sensor Module Assemblers
    • 2.4 Package and Module Integrators
    • 2.5 Apple's Touch ID Sensors
    • 2.6 Smartphones/Tablets with Fingerprint Sensors
    • 2.7 Fingerprint Sensor OSATs
    • 3.1 FC-BGA/LGA Substrate Market Forecast
    • 3.2 FC-CSP Substrate Market Forecast
    • 3.3 FC-PBGA Substrate Trends
    • 3.4 FC-CSP Substrate Trends
    • 3.5 Emerging Packaging Technology Platform
    • 3.6 EMIB versus Silicon Interposers
    • 3.7 Interposer Design Rule Comparison
    • 3.8 Organic Interposer Suppliers and Technology
    • 3.9 APX Technology Roadmap
    • 3.10 iTHOP® Features
    • 4.1 Build-up FC-PBGA Substrate Suppliers
    • 4.2 Build-up FC-CSP Substrate Suppliers
    • 4.3 Laminate PBGA/CSP Substrate Suppliers
    • 4.4 through 4.40 Design Rules for Substrates
      • ASE, AT&S, Daeduck, Daisho Denshi, Eastern, FICT, Ibiden, CoreEZ®, HyperBGA®, i3 Electronics, Kinsus, Kyocera, LG Innotek, Nan Ya, SEMCO, SCC, Shinko Electric, Simmtech, Toppan, Tripod, Unimicron
Stacks Image 25201
brochure
  • Published March 2016
  • 80 pages
  • 13 figures / 57 tables
  • 25 PowerPoint slides
  • $4,995 annual subscription (4 issues)
    $2,500 single issue
    $8,500 corporate license
